Fully Configured: Bicycle lithium battery modified 26 inch front drive kit includes 36V 250W front drive 26 inch motor wheel, 15A controller, LCD7U meter, thumb throttle, 8 magnetic assist sensor, power off brake handle, controller box and manual. Aluminum Alloy: The brushless gear hub DC motor is made of aluminum alloy rim and processed with fine craftsmanship, which effectively enhances the edge of the rim, looks light, has strong bearing capacity, and is far more comfortable than other types of motors, realizes noise free operation, and allows you to fully enjoy riding. Circuits Protection: The controller shell is made of high quality metal material with grooved design, it protects the internal circuit from thermal overload due to good heat dissipation. The instrument is made of high quality ABS plastic material, which is light, strong and durable, with fine workmanship, good toughness and waterproof performance, providing better protection for the internal circuit and making it more durable. Panel Function: LCD7U display panel will display a lot of useful data on your bike, such as power display, backlight display, headlight display, brake display, one way time, total travel time, current speed, average speed, maximum speed, total one way distance, power assisted mode 6km/h, etc. Application: 36V 250W front drive 26 inch motor wheel kit suitable for electric bikes with lithium battery modified front drive motor wheels for bicycles mountain bikes, DIY electric bikes, electric bikes, electric scooters, folding bikes, etc. Easy to maintain, electric bike mopeds, mountain bike modification conversion motors, high efficiency, which greatly improves the riding pleasure and is suitable for cyclists who like challenges. Item Type: Bicycle lithium battery modified front drive motor wheel kit Material: Stainless steel, aluminum alloy, ABS plastic Weight: Approx. 6300g / 222.23oz Motor Wheel Type: Front drive motor wheel (waterproof joint) Motor Rated Voltage: 36V Motor Rated Power: 250W Motor Speed: About 25-28km/h Motor Speed: 207-270 Rpm Motor Torque N. M: 29-31.2 N. M Motor Opening Size (mm): 100mm / 3.94in Motor Matching Controller Current: 15A Motor Rim: P19D Motor Torque Arm: M14 Brake Disc for Motor: 160mm / 6.30in Motor Brake Type: V brake / disc brake universal Motor Wheel Position: Front wheel Motor Structure: Brushless gear motor Motor Magnet Height: 24H Motor Magnet Pole Number: 20 Motor Operating Temperature: Minus 20°-45° Controller Connector Type: Ordinary connector (except motor waterproof connector) Controller Rated Voltage: DC 36V/48V Controller Rated Current: 7A Controller Maximum Current: 15±1A Controller Speed Setting: 1-4.2V Controller Brake Input: low level Controller Low Voltage Protection: DC 30/40±0.5V Controller wire color definition: 1. Black Single Big Head Wire: Motor wire (waterproof connector) 2. Red and Black Single Big Head Wire: Power Wire 3. Red, Blue, Black, Green and Yellow Single Row Five Wire Port: Instrument line (5pin) 4. Red and Blue Wires (two): Power off brake handle line 5. Red and Black Wires: Throttle dial line (3pin) 6. Brown, Black and Yellow line: Power assist sensor wire (3pin) LCD7U panel functions: Up button, switch, button, button down, power assist sensor indication, battery capacity indicator, power, cruise function, one way time, total travel time, the gas shows, 6 km/h thrust power system, the cycling speed (system), the cycling speed (imperial system), maximum speed, average speed, distance (system), distance (imperial system), travel distance, total distance, battery voltage, brake display, backlight and headlights, bluetooth display. 1 x Motor Wheel. 1 x Panel Manual. 2 x Power Off Brake Handle. 1 x Throttle Shifter. 1 x Power Assist Sensor. 1 x Controller Box. 2 x Controller Box Mounting Ring. 8 x Controller Box Screw. Pay attention to the rim opening. We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. Post a message again because sometimes our message system may block some emails. If you are satisfied with our service, pls. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We will do our up most to exceed your expectations in customer service, communication and dispatching of your orders.
